# Specifications

<figure><img src="/files/gH7izqlzdNdC0S57WJcL" alt=""><figcaption></figcaption></figure>

| Parameter              | Value                            |
| ---------------------- | -------------------------------- |
| Input Voltage          | 12V – 60V DC                     |
| Output Voltage         | 5V DC (regulated)                |
| Maximum Output Current | 4A                               |
| Output Power           | 20W                              |
| Efficiency             | \~87% at full load               |
| Output Ripple          | < 200mV (typical)                |
| Switching Frequency    | 400 kHz                          |
| Mode                   | Continuous Conduction Mode (CCM) |
| Load Regulation        | ±3.65% (typical)                 |
| Operating Temperature  | -40°C to +85°C (ambient design)  |
| Size                   | 36x15mm                          |
